Passive UHF RFID tags are a cost-optimized solution designed for inventory management, asset tracking, and supply chain management in small and medium-sized enterprises. Operating at 860-960MHz, compatible with the EPC Gen2 (ISO 18000-6C) standard, and supporting batch sensing and reading, they significantly improve inventory efficiency and reduce labor costs. The passive design eliminates the need for an internal battery, powered by the reader's radio frequency field, boasting a lifespan of over 10 years and zero maintenance costs. The tags are thin, self-adhesive stickers with strong adhesive backing, easily applied to cartons, shelves, pallets, or asset/equipment surfaces. They support customized EPC coding (SKU, asset number, etc.) and barcode/text printing, enabling dual recognition of RFID electronic codes and visual codes. Suitable for various scenarios such as warehouse inventory management, IT asset tracking, tool inventory, and document management, they are a cost-effective entry-level choice for intelligent management.

What Is RFID Tag?

A Radio Frequency Identification Tag (RFID tag) is an electronic tag that exchanges datawith a RFID reader through radio waves.

Most RFID tags are made up of at least two main parts. The first is an an antenna, whichreceives radio frequency (RF) waves. Thesecond is an integrated circuit (IC), which is usedfor processing and storing data, as well as modulating and demodulating the radio wavesreceived/sent by the antenna.

How Does A RFID Tag Work?

Reader transfers energy to the transponder by emitting electromagnetic waves throught air.

Transponder uses RF energy to charge up.

Transponder receives command/data signal and responds accordingly.

Reader receives transponder response and process accordingly. ie. sent to a host computer or externaldevices through its control lines

Specifications
Main Specifications
Brand	GSRFID
Product Name	RFID Windshield Tags
Performance Parameters
Frequency	860-960Mhz
Protocol Support	ISO 18000-6C / EPC Gen2
Dimensions	102×32mm / 70×40mm / 50×30mm / Customizable
Material	PET / Coated Paper / Synthetic Paper
Chip	Impinj Monza R6 / R6-P / Alien Higgs-3 / NXP UCODE 8/9/ Customizable
Memory	128bit, 256bit
Reading Distance	1-15m
Package	1000-2500pcs/roll, 4 rolls /carton
Applications	Warehouse inventory counting, IT asset tracking (computers/servers/monitors), office equipment management, document and file labeling, retail shelf management, tool/instrument inventory, library/archives.
Operating Environment
Operating Temperature	-70℃/ 20%~90% RH.
Storage Temperature	-20~50℃ / 20%~90% RH(Without condensation).

How to distinguish RFID labels

Normal RFID label
Used on non-metallic and liquid surfaces
Soft on-metal RFID label

Used on metallic surfaces,with a longer reading range
Anti-liquid RFID label
Used on containers containing liquids, with a long reading range
Washable RFID label

Washable,corrosion-resistant,and high-temperature resistant

Production customization process

Production customization：

GSRFID boasts over 20 years of RFID tag and sticker OEM/ODM experience, providing superior product quality and customized services. We have a dedicated production plant of over 5,000 square meters, equipped with multiple automated production lines. Our products are ISO9001, CE, and FSC certified, ensuring product quality. The company possesses advanced testing equipment and a professional R&D team. We can customize RFID tags to meet your project requirements. Inquire now!

Packing&Shipping

FAQ

Q: Is your company a factory? Do you have a price advantage compared to other suppliers?

A: Yes, we are an RFID tag manufacturer with a significant price advantage, while guaranteeing product quality and supply stability.

Q: Can I get samples before placing orders?

A: Yes, We can provide free samples.

Q: What is the delivery time after I place an order?

A: Delivery time is 7-12 days, and for customized products, it is generally 15-25 days depending on the complexity. Expedited delivery can be negotiated.

Q: What customization requirements are supported?

A: Yes, we support full customization, including custom sizes, chips, printing, and data writing.

Q: Do flexible anti-metal tags have a long reading range?

A: Excellent read range, Our flexible anti-metal tags feature a special antenna design that provides a read range approximately 20% to 30% greater than that of other similar products.

Q: What certificates do you have?

A: Yes, we have FSC, CE, ROHS, ISO9001, etc.
